TZF-Q series of exhaust gas purification machine

  • Overview:

    The exhaust gas is firstly collected by the absorption port and adjusted to the optimal flow rate by the flow regulating valve. The adjusted exhaust gas is collected by the branch pipe from the branch pipe to the supervisor and then enters the exhaust gas purification unit for catalytic oxidation and is highly oxidized under the action of the catalyst. The reaction principle is at room temperature and pressure, and the oxidant electron coupling, resulting in a more stable hydroxyl radicals or peroxide radicals. These free radicals have very strong oxidizing properties and can react with the organic compounds in the exhaust gas. The organic radicals generated by the reaction can continue to participate in the chain reaction. Will not be absorbed by the chemical absorption of organic gases in the exhaust gas decomposition of unsaturated hydrocarbons, hydrocarbon unsaturated hydrocarbons in the rapid oxidation of H2O and CO2, so as to achieve the purpose of the exhaust gas purification. This process runs low cost, no clogging, long-term stable operation, safe and reliable.

  • Details
  • Features
  • More

    First, the composite catalytic oxidation of exhaust gas purification equipment Overview:
    Composite catalytic oxidation device is our patented product (Patent No .: ZL201420512620.9)
    Process principle: the use of the corresponding catalytic oxidant to the chemical degradation of harmful gases, mixed contact reaction, and then collided with the oxidant to make it into harmless substances, and finally through the demister fog discharge standards.
    The exhaust gas is firstly collected by the absorption port and adjusted to the optimal flow rate by the flow regulating valve. The adjusted exhaust gas is collected by the branch pipe from the branch pipe to the supervisor and then enters into the exhaust gas purification unit for catalytic oxidation and is highly oxidized under the action of a catalyst. The reaction principle is at room temperature and pressure, and the oxidant electron coupling, resulting in a more stable hydroxyl radicals or peroxide radicals. These free radicals have very strong oxidizing properties and can react with the organic compounds in the exhaust gas. The organic radicals generated by the reaction can continue to participate in the chain reaction. Will not be absorbed by the chemical absorption of organic gases in the exhaust gas decomposition of unsaturated hydrocarbons, so that hydrocarbons in the unsaturated hydrocarbons quickly oxidized into H2O and CO2, so as to achieve the purpose of the exhaust gas purification. This process runs low cost, no clogging, long-term stable operation, safe and reliable.


    Second, the advantages:
    1, can efficiently remove volatile organic compounds VOCs, sulfur dioxide, hydrogen sulfide, nitrogen oxides, non-methane total hydrocarbons, ammonia, benzene, toluene, xylene, formaldehyde, acetone, butanone, indole, nitro, sulfur Ether, mercaptans, phenols and other major pollutants, as well as a variety of odor, deodorization efficiency of up to 99% or more, deodorant effect greatly exceeded the national 1993 enactment of the stench pollutant discharge standards (GB14554-93) and 1996 Year "issued by the" Air Pollutant Comprehensive Emission Standard "(GB16297-1996).
    2, low operating costs, low operating costs of treatment chemicals, long-term operation will not block the phenomenon does not rebound.
    3, adaptable: adapt to a variety of high concentrations, the amount of the atmosphere, different industrial VOCs volatile organic compounds, inorganic substances and malodorous gases, purification efficiency, continuous 24-hour operation, safe and reliable operation.
    4, a high degree of automation: the entire exhaust gas treatment system using PLC automatic control to achieve remote control and monitoring.


    Third, use:
    This product is widely used in the oil industry, chemical plants, printing plants, paper mills, coking plants, sewage treatment plants, waste treatment plants, sludge drying plants, pharmaceutical plants, food processing plants, recycled rubber plants, rubber products factory, plastic Products factory, tire factory, galvanizing plant, metal products factory, paint factory, fertilizer plant, fertilizer plant, furniture factory, and all harmful and toxic gas emissions applications.


    Fourth, the exhaust gas detection comparison table:
    The equipment through the Beijing Municipal Environmental Protection Bureau authority certification testing, testing reports recognized by international and domestic authorities, fully meet the state requirements of the emission standards.

    VOCs exhaust gas purification one machine

           A variety of VOCs discharged from the storage tank are firstly collected in the pipeline and then entered into the multi-stage condensation and liquefaction process. Then, a series of reactions such as chemical absorption, catalytic oxidation and demisting are carried out.

    Fifth, the equipment parameters:
